Morse Code – Revisited using the BBC micro:bit

As mentioned last week, I have found a new way to provide a front end processor for my Pi, the BBC micro:bit. This week, I have started putting the new system through its paces: The microbit class in our GitHub repository has been beefed up to make it more resilient in the case where serial I/O is not initialised, or the MicroPython REPL is not running, and I have added a trivial Python program which can be used to intialise the REPL using the mu editor.

To test it all, I have revisited the Morse Code example, originally written to use GPIO support provided by Quick2Wire, to see if I could get it up and running with my new infrastructure. The micro:bit has a 5×5 LED display which makes the result a bit more impressive to look at:



The new code is significantly simpler than the original, for a couple of reasons:

  1. Making calls to the micro:bit API via MicroPython is easier than using GPIO via a C library.
  2. Version 15.0 of Dyalog APL contains new system functions for working with text files, so we no longer need the “Files” library, we can just use the built-in ⎕NGET function to read the contents of a file.

Raspberry APL Pi and Python on the micro:bit

A couple of years ago I spent many happy hours writing APL code to control robots which each embedded a Raspberry Pi. It was fun but it was a bumpy ride – my interest eventually faded when I discovered that it was just too difficult to make sense of raw accelerometer data, which I was hoping to use for precise navigation. After I managed to fry my MPU-9150, I decided to pursue other interests, as they say.

Recently, Romilly Cocking has been waxing lyrical about a number of new components which he thinks will make the whole experience more enjoyable – and I have decided to dive back in. So far, it has indeed been a very pleasant experience.

The Raspberry Pi Model 3

The Raspbery Pi Model 3While I was away, the Raspberry Pi and the software available for it have come a VERY long way. The speed of a Pi 3 makes it a perfectly usable computer. I am writing this blog entry on the Pi using a standard Chromium browser. APL starts up immediately, using our new graphical IDE. It is quite simply amazing!

The BBC micro:bit and MicroPython

The first generation of APL-based robots used an Arduino to manage the motors and sensors because timing was too critical for the Pi to handle it. I spent some rather unhappy hours writing a control program in C, debugging that without any tools. You could not even do “printf debugging” to the serial port because that interfered with the timing so much that it stopped everything from working.

Romilly suggested I take a look at the micro:bit, and since I have been using an interactive REPL all my life, he suggested that I run MicroPython on it.

He was right, I’m loving it!

Getting Started

I purchased the Kitronik Inventors’s Kit for the micro:bit from Pimoroni, and quickly found videos on Youtube explaining how to assemble it. I installed the “mu” editor on my Pi and was immediately able to edit a simple Python program and run it on the micro:bit.

My next step was, of course, to create a little class to drive MicroPython from APL. This involves using serial I/O: when the micro:bit is attached to your Pi via USB it appears as a folder and as a serial (tty) device, typically /dev/ttyACM0. You can find my code in the APLPi/microbit GitHub repository.

If you clone the repository to /home/pi/microbit and start APL, you can make calls to the MicroPython repository along the lines of:

    ]load /home/pi/microbit/microbit
    mb←⎕NEW microbit ''
    mb.PyREPL '2+2'
4

Using Python on the micro:bit to do maths isn’t that interesting when you have APL on the Pi; the exciting thing is that we can call the micro:bit Python API and access the hardware. My first experiment was to display my favourite APL symbol (Grade Up – aka Imperial Cruiser) in the built-in 5×5 LED display:

Imperial Cruiser on  the micro:bit

APL displaying an Imperial Cruiser on the micro:bit

Which of the Inventor’s Kit experiments would you like to see me do next?

The 2016 Year Game

Our 2016 Year Game was launched in January 2016 and ran until the end of the year. The idea was simple – to find APL expressions involving exactly the digits 2 0 1 6 in that order to equal the numbers 0 to 100 using the fewest characters possible. The minimum number of characters for an expression is 5 (the four digits 2 0 1 6 and a single primitive function/operator) so the smallest number of characters that a possible solution can have is 505.

A lovely elegant solution was pointed out by Lars Stampe Villadsen:

      ⎕IO←0
      {⍪⍳+/⍵*⌽⍵}2 0 1 6

and Bernard Legrand submitted two one-line solutions:

      (⍴⍬),⍳¯20+!1-⍨6

and

      (⍴⍬),⍳⍴'Be happy: this solution to Game 2016 will be the most stupid one, but it needs only five APL symbols'

These three each return all the numbers from 0 to 100. Not valid submissions for this particular game, but I did find them rather pleasing. Anthony Cipriano was inspired to go one step further and submitted an expression that creates the first 8 Fibonacci numbers:

      (⊢,(+/{(¯2∘↑)⍵}))/(⊂0 1),⍨⍳6

The wonderfully varied ways in which APL can be used (and in which APL users think!) was illustrated beautifully by some of the solutions. Although some numbers were attained in the same way by everyone (36, for example, was always 20+16), others lent themselves to multiple solutions. No-one managed to calculate 100 in fewer than 7 characters, but the 7-character answers included 20∧⌹.16, 20ׯ1+6, -20×1-6, 20×-1-6, ¯20×1-6 and various others on the same theme. Unity experienced similar creativity, with 1 being reached in the minimum possible number of characters (5) using ×2016, 201≢6, 20>16, 20≠16, 2<016, etc.

It was clear early on that submissions fell into two distinct groups – those who wrote a program to find the expressions and those who derived their expressions manually. I found the creativity evident in the manually-derived solutions very satisfying; the results may not have been as terse as those resulting from programs, but the individuality of the creators shows people inspired by their subject matter. Who can fail to appreciate the thought process behind arriving at 96 using (×/+\+\(!2 0 1))+6 rather than the more prosaic ⌈⍟!20+16 or ⎕IO-⍨+⍨20+16 rather than 20+⌈○16 for 71?

Having said that, the goal was conciseness and individual character counts are now tabulated on the 2016 Year Game page; an amalgamation of the lowest-character expressions that anyone achieved can also be downloaded from this page. Congratulations to Jonas Stensiö and Veli-Matti Jantunen, who both achieved the same character count as the amalgamated minimum (693).

(most names omitted to protect the not-so-innocent)
